Enovix has designed a high-energy, high-capacity battery with a 100% silicon anode to power the technologies of the future.
Silicon has long been heralded as the next important anode material. Silicon anodes can theoretically store more than twice as much lithium than the graphite anode that is used in nearly all Li-ion batteries today (1800mAh/cm3 vs. 800mAh/cm3).
Silicon’s high energy density, however, creates four significant technical problems that Enovix has solved:
Enovix cells have a stainless-steel constraint system surrounding the cell that limits the battery from swelling. We also reorient the electrodes to face a small side of the battery to decrease the required constraining force.
Enovix has developed a “pre-lithiation” process during manufacturing to insert additional lithium source to top-off lithium trapped at formation.
Our batteries can do this practically because the additional lithium only needs to travel a short distance in our architecture to permeate the anode.
Enovix manages swelling as a result of cycling with its integrated constraint, limiting swelling to as little as <2% cell thickness after 500 cycles.
The Enovix integrated constraint keeps particles under constant stack pressure, limiting particles from electrically disconnecting and cracking.
Expanded View
Closed View
It wasn’t enough to reimagine the lithium-ion battery, we’ve also introduced a whole new level of safety.
Enovix has applied an innovative approach to Li-ion battery production. The result is precision production tools that have the potential to increase megawatt hour (MWh) capacity relative to a conventional Li-ion battery production line at the same volume. Providing an opportunity for Enovix to achieve a cost-effective, high-volume production process for silicon-anode Li-ion batteries. Just in time for the future.TM
See why the Enovix 100% active silicon anode cell is the most significant battery architecture advancement in the last 30 years.
Designed for wearable and IoT
High energy density
Small form factor solution
Compatible with standard lithium-ion battery safety circuits and battery management systems
Designed for smartphones and IoT devices
High energy density
High cycle life
Large form factor solution
Supports fast charge
Compatible with standard lithium-ion battery safety circuits and battery management systems
Designed for portable power, military and industrial applications
High energy density
BrakeFlow™ Support
Rugged cell architecture
Compatible with standard lithium-ion battery safety circuits and battery management systems
Contact our sales team today to schedule a presentation and discuss your project.
